30/33-8, 3638405M91, 3638405Z91, 4224523M91, 742621M91, 89209, 89214, U5LP0034,
Landini
Tractor
Serie: 30
5530L, 5530V, 5830,
Serie: 40
5840,
Serie: 500
5500,
Serie: 60
5560F, 5560L, 5860,
Serie: 70
5870,
Serie: Advantage
55F, 55FP, 55GE, 55GT, 55GTP, 55L, 55LP,
Serie: Blizzard
Blizzard 50,
Serie: Cingolati
C5500, C5830, CF5030, CF5830,
Serie: Globus
Globus 50,
Serie: Trekker
CF55,
Serie: Vigneti
Vigneti 55V,
Massey Ferguson
Tractor
Serie: 100
133, (4 ring piston ), 134C, (4 ring piston ), 134V, (4 ring piston ), 135, (4 ring piston ), 135V, (4 ring piston ), 140, (4 ring piston ), 145, (4 ring piston ), 145S, (4 ring piston ), 145V, (4 ring piston ), 148, (4 ring piston ), 150, (4 ring piston ), 152, (4 ring piston ), 152F, (4 ring piston ), 152MKIII, 152S, (4 ring piston ), 152V, (4 ring piston ), 154, (4 ring piston ), 154C, (4 ring piston ), 154F, (4 ring piston ), 154S, (4 ring piston ), 154V, (4 ring piston ), 155, (4 ring piston ), 158, (4 ring piston ), 158F, (4 ring piston ), 158MKIII, 158S, (4 ring piston ), 158V, (4 ring piston ), 165, (4 ring piston ),
Serie: 200
230, (4 ring piston ), 233, (4 ring piston ), 234C, (4 ring piston ), 234CF, (4 ring piston ), 234S, (4 ring piston ), 235, (4 ring piston ), 240, (4 ring piston ), 240S, 244CF, (4 ring piston ), 245, (4 ring piston ), 250, (4 ring piston ), 253, (Italy), (4 ring piston ), 254, (4 ring piston ), 254C, (4 ring piston ), 254CF, (4 ring piston ), 254S, (4 ring piston ), 255, (4 ring piston ), 260, (4 ring piston ),
Serie: 2200
2205, (4 ring piston ),
Serie: 300
333, (4 ring piston ), 334V, (4 ring piston ), 340, (4 ring piston ), 342, (4 ring piston ), 350, (4 ring piston ), 353, (4 ring piston CE31197, CE31212 ), 353LX, (4 ring piston CE31197, CE31212 ), 353S, (4 ring piston CE31197, CE31212 ), 354AP, (4 ring piston CE31197, CE31212 ), 354AQ, (4 ring piston CE31197, CE31212 ), 354F, (4 ring piston CE31197, CE31212 ), 354FP, (4 ring piston CE31197, CE31212 ), 354FP(X), (4 ring piston CE31197, CE31212 ), 354FQ, (4 ring piston CE31197, CE31212 ), 354GE, (4 ring piston CE31197, CE31212 ), 354GE(X), (4 ring piston CE31197, CE31212 ), 354S, (4 ring piston CE31197, CE31212 ), 354SP, (4 ring piston CE31197, CE31212 ), 354SP(X), (4 ring piston CE31197, CE31212 ), 354SQ, (4 ring piston CE31197, CE31212 ), 354V, (4 ring piston CE31197, CE31212 ), 354VQ, (4 ring piston CE31197, CE31212 ), 356CF, (Parallel liner ),
Serie: 3200-3300
3210FP(X), (Parallel liner ), 3210GE(X), (4 ring piston ), 3210SP(X), (4 ring piston ),
Serie: 35
65, (4 ring piston ),
Serie: 500
550, (4 ring piston ), 560, (4 ring piston U589379L Cast iron liner ),
Serie: 700-800
765, (4 ring piston ),
Industrial tractor
Serie:
20, (4 ring piston ), 203, (4 ring piston ), 205, (4 ring piston ), 20B, (4 ring piston ), 20C, (4 ring piston ), 20D, (4 ring piston ), 20E, (4 ring piston ), 20F, (4 ring piston ), 2135, (4 ring piston ), 2203, (4 ring piston ), 30, (4 ring piston ), 302, (4 ring piston ), 304, (4 ring piston ), 30B, (4 ring piston ), 30E, (4 ring piston ), 30H, (4 ring piston ), 3165, (4 ring piston ), 3303, (4 ring piston ), 3305, (4 ring piston ), 356, (4 ring piston ), 40, (4 ring piston CE22438 ), 40B, (4 ring piston ), 50, (4 ring piston ),
Motor:
AD4.203 - Perkins
AD3.152 - Perkins
Landini
Tractor
Serie: 30
5530L, 5530V, 5830,
Serie: 40
5840,
Serie: 500
5500,
Serie: 60
5560F, 5560L, 5860,
Serie: 70
5870,
Serie: Advantage
55F, 55FP, 55GE, 55GT, 55GTP, 55L, 55LP,
Serie: Blizzard
Blizzard 50,
Serie: Cingolati
C5500, C5830, CF5030, CF5830,
Serie: Globus
Globus 50,
Serie: Trekker
CF55,
Serie: Vigneti
Vigneti 55V,
Massey Ferguson
Tractor
Serie: 100
133, (4 ring piston ), 134C, (4 ring piston ), 134V, (4 ring piston ), 135, (4 ring piston ), 135V, (4 ring piston ), 140, (4 ring piston ), 145, (4 ring piston ), 145S, (4 ring piston ), 145V, (4 ring piston ), 148, (4 ring piston ), 150, (4 ring piston ), 152, (4 ring piston ), 152F, (4 ring piston ), 152MKIII, 152S, (4 ring piston ), 152V, (4 ring piston ), 154, (4 ring piston ), 154C, (4 ring piston ), 154F, (4 ring piston ), 154S, (4 ring piston ), 154V, (4 ring piston ), 155, (4 ring piston ), 158, (4 ring piston ), 158F, (4 ring piston ), 158MKIII, 158S, (4 ring piston ), 158V, (4 ring piston ), 165, (4 ring piston ),
Serie: 200
230, (4 ring piston ), 233, (4 ring piston ), 234C, (4 ring piston ), 234CF, (4 ring piston ), 234S, (4 ring piston ), 235, (4 ring piston ), 240, (4 ring piston ), 240S, 244CF, (4 ring piston ), 245, (4 ring piston ), 250, (4 ring piston ), 253, (Italy), (4 ring piston ), 254, (4 ring piston ), 254C, (4 ring piston ), 254CF, (4 ring piston ), 254S, (4 ring piston ), 255, (4 ring piston ), 260, (4 ring piston ),
Serie: 2200
2205, (4 ring piston ),
Serie: 300
333, (4 ring piston ), 334V, (4 ring piston ), 340, (4 ring piston ), 342, (4 ring piston ), 350, (4 ring piston ), 353, (4 ring piston CE31197, CE31212 ), 353LX, (4 ring piston CE31197, CE31212 ), 353S, (4 ring piston CE31197, CE31212 ), 354AP, (4 ring piston CE31197, CE31212 ), 354AQ, (4 ring piston CE31197, CE31212 ), 354F, (4 ring piston CE31197, CE31212 ), 354FP, (4 ring piston CE31197, CE31212 ), 354FP(X), (4 ring piston CE31197, CE31212 ), 354FQ, (4 ring piston CE31197, CE31212 ), 354GE, (4 ring piston CE31197, CE31212 ), 354GE(X), (4 ring piston CE31197, CE31212 ), 354S, (4 ring piston CE31197, CE31212 ), 354SP, (4 ring piston CE31197, CE31212 ), 354SP(X), (4 ring piston CE31197, CE31212 ), 354SQ, (4 ring piston CE31197, CE31212 ), 354V, (4 ring piston CE31197, CE31212 ), 354VQ, (4 ring piston CE31197, CE31212 ), 356CF, (Parallel liner ),
Serie: 3200-3300
3210FP(X), (Parallel liner ), 3210GE(X), (4 ring piston ), 3210SP(X), (4 ring piston ),
Serie: 35
65, (4 ring piston ),
Serie: 500
550, (4 ring piston ), 560, (4 ring piston U589379L Cast iron liner ),
Serie: 700-800
765, (4 ring piston ),
Industrial tractor
Serie:
20, (4 ring piston ), 203, (4 ring piston ), 205, (4 ring piston ), 20B, (4 ring piston ), 20C, (4 ring piston ), 20D, (4 ring piston ), 20E, (4 ring piston ), 20F, (4 ring piston ), 2135, (4 ring piston ), 2203, (4 ring piston ), 30, (4 ring piston ), 302, (4 ring piston ), 304, (4 ring piston ), 30B, (4 ring piston ), 30E, (4 ring piston ), 30H, (4 ring piston ), 3165, (4 ring piston ), 3303, (4 ring piston ), 3305, (4 ring piston ), 356, (4 ring piston ), 40, (4 ring piston CE22438 ), 40B, (4 ring piston ), 50, (4 ring piston ),
Motor:
AD4.203 - Perkins
AD3.152 - Perkins
Pentru identificarea corecta a unui piston sau set de segmenti avem nevoie de cateva indicii:
Agentul de vanzari va poate cere unele informatii din urmatoarele:
Iata care sunt acestea si cum pot fi identificate.
 |
Intoarceti pistonul invers si masurati diametrul exterior Indiferent ca pistonul este cu "aripi" sau drept ca, cel din imagine, masurati intotdeauna in partea de jos a acestuia. Aceasta cota este implicit interiorul cilindrului si diametrul segmentilor REMARCA: Pastrand pozitia si rotind pistonul puteti descoperi o eroare de 0.01 / 0.3 mm. Acesta este un lucru absolut normal de fabricatie. |
 |
Diametrul boltului Pentru o mai buna precizie puteti masura diametrul exterior al boltului. |
| Distanta din centrul imaginar al boltului pana la camera de ardere: Incercati o aranjare a instrumentului de masurat asemanatoare cu cea din imagine |
 |
 |
<-- Grosime unui segment. ( foto stanga ) |
| Nu incercarti sa masurati segmentii din exterior: - Riscati sa ii distrugeti ! - Diametrul exterior al acestora este intotdeauna identic cu exteriorul pistonului din prima figura |
.jpg?1492117795396) |
Pozitionati segmentul asemenea imaginii:
Doar asa va puteti da seama cu ochiul liber daca segmentul este conic ( trapez ) sau nu.
